Gefrierschrank SWUF UniFreeze SmartLab 82 Liter -86°C
ArtikelnummerDH.SWUF0075
MengeneinheitStück
Ultra-Low Temperature Freezer, digital, type SWUF-80,
Upright type,
temperature range: -86°C to -65°C,
capacity: 82 Liter,
with ergonomic 7"-Full-Touchscreen TFT LCD (Smart-Lab™ Controller),
with WiRe™-App- and web service,
internal dimension: 340 x 485 x 520 mm,
external dimension: 530 x 687 x 1060 mm,
no protection against explosion,
incl. 1 stainless steel shelf,
power supply: 230 V, 1 phase, 50/60 Hz
Ideal for:
ultra low refrigeration
Features:
personal-type compact ultra-low temperature freezer
freeze down to -86°C
CFC-free refrigerant
external temperature sensor hole
block condenser removes filter
filter-free mechanism lowers heat from the compressor
easy maintenance and improved performance
high-quality insulation panel and inner doors (powder-coated stainless steel) ensure defrosting around outer surface
stainless steel interior and powder-coated steel body
CE, UL/CUL & RoHS certified and unique serial number for tracing
Safety mechanism:
push alarm service to your smartphone
sensor error detection
door locking system, door open error
door ajar and power failure alarm
standard warning and alarm functions
Controller:
Smart-Lab™ controller with 7? full touch screen TFT LCD:
WiRe™ app service, remote control system
variable program settings
self-diagnostic function
automatic data recording
data transfer to PC by USB memory
Internet connectivity with WiFi
Features
UniFreezeTM system:Single compressor ensures temperatures down to -86°C, minimized power consumption and minimized noise level.
Green product
RoHs certified:No hazardous substances (Pb, Cd, Hg, Hex-Cr, PBB, PBDE) are used in all UniFreezeTM and DuoFreezeTM freezers!
Natural refrigerants:Instead of using HFC refrigerants (R-134a, R-404A, R-507) all UniFreezeTM and DuoFreezeTM models have a specially mixed refrigerant mostly consisting of natural materials.
Power consumption:Up to 39% lower than the average competitor.
SMART-LabTM Controller:
full touch screen TFT LCD:
WiRe™ app service, remote control system
variable program settings
self-diagnosis function and interactive temperature graph
automatic data recording and password protection
data transfer to PC by USB memory
digital calibration (offset function)
min-/max-temperature memory & program function
push-alarm service to smartphone or tablet PC
Version
Max. rack quantity: 4 pcs. with 12 (3 x 4) placed racks (RFU8)
Width (Outer)
530 mm
Height (outer)
1060 mm
Length (outer)
687 mm
Ideal for
Ultra low refrigeration
Width (inner)
340 mm
Shelves
1 stainless steel shelf included
Weight
60 kg
Weight with packaging
102 kg
Height (inner)
520 mm
Capacity
82 l
Compressor
Hermetic type
Condenser
Block condenser, no pin, filter-free
Refrigerant
CFC-free refrigerant
Length (inner)
485 mm
Power consumption
321 W/h
Temperature range
-86°C to -65°C, at 30°C room temperature & 70% humidity
Packing size
960 x 760 x 1350 mm
Sensor
Temperature sensor PT100
